Positive Achromatic Doublets Lenses

Achromatic Doublets Lenses bridge the gap between color-corrected achromats and spherical aberration corrected aspheres, resulting in cost effective, color corrected aspheric components.

Material:See table below

Design Wavelength:A:486.1nm 587.6nm 656.3nm

                    B:706.5nm 855nm 1015nm

                    C:1016nm 1330nm 1550nm

Focal Length Tolerance:±1%

Diameter Tolerance:+0.0/-0.1mm

Thickness Tolerance:±0.2mm

Surface Accuracy:λ/4@632.8nm

Surface Quality:60-40

Centration:<3'

Clear Aperture:>90%

Coating:AR

        A:350-650nm

        B:650-1050nm

        C:1050-1580nm
