Wavelength:405nm
Output power:1mW,5mW,10mW,20mW,30mW,50mW,100mW,150mW
Beam Divergence:0.1mrad ~ 0.6mrad
Operating Voltage:DC6V
Operating Temperature:-10℃～70℃
Storage Temperature:-30℃～80℃
Dimensions:Φ16x60mm
Specifications:
Wavelength:405nm
Output power:1mW,5mW,10mW,20mW,30mW,50mW,100mW,150mW
Beam Divergence:0.1mrad ~ 0.6mrad
Operating Voltage:DC6V
Operating Temperature:-10℃～70℃
Storage Temperature:-30℃～80℃
Dimensions:Φ16x60mm
MTTF: 8000 hours
Characteristics:
High-quality laser diode,optical glass lens, driver circuit and housing
Better line quality
High reliability, high stability, long life,low price
Applications:
Laser alignment and positioning
Surveying equipments
Laser medical equipment
