Wavelength:405nm
Output power:1mW,5mW,10mW,20mW,30mW,50mW,100mW
Beam Divergence:0.1mrad ~ 0.6mrad
Operating Voltage:DC6V
Line thickness: 2mm at 5m
Fan angle：90°
Laser line accuracy：<30”(at 5m)
Specifications:
Wavelength:405nm
Output power:1mW,5mW,10mW,20mW,30mW,50mW,100mW
Beam Divergence:0.1mrad ~ 0.6mrad
Operating Voltage:DC6V
Line thickness: 2mm at 5m
Fan angle：90°
Laser line accuracy：<30”(at 5m)
Operating Temperature:-10℃～60℃
Storage Temperature:-30℃～80℃
Dimensions:Φ16x60mm
MTTF: 10000 hours
Characteristics:
High-quality laser diode,optical glass lens, driver circuit and housing
Better line quality
High reliability, high stability, long life,low price
Applications:
Machine vision
Industrial inspection
Industrial marking devices
3D contour mapping
Positioning & visualization
Biomedical
High-end alignment
Laser targeting devices and so on.
