Wavelength:532nm
Output power:1-15mW
Operating Voltage:DC3V
Line thickness: Less then 2mm at 3m
Fan angle: 10°, 30°, 45°, 60°, 75°
Laser line accuracy: <30”(at 5m)
Operating Temperature: 10℃～35℃
Specifications:
Wavelength:532nm
Output power:1-15mW
Operating Voltage:DC3V
Line thickness: Less then 2mm at 3m
Fan angle: 10°, 30°, 45°, 60°, 75°
Laser line accuracy: <30”(at 5m)
Operating Temperature: 10℃～35℃
Storage Temperature: -20℃～50℃
Dimensions:Φ16×70mm
Characteristics:
High-quality laser diode,optical glass lens, driver circuit and housing
Better line quality
High reliability, high stability, long life,low price
Applications:
Laser alignment and positioning
Surveying equipments
Line laser module laser locate on sewing machine, clothes process,shears, clippers machine
Tyre laser locate,saw machine,power machine
Stage lighting and so on
